Excellent traction allows sharp braking
Large ground contact ratio provides good stability and driving comfort
Cut resistance and wear resistance rubber compound, adapted to harsh working condition
CTL Track
TAITE
-
Taite Patented L Pattern
-
Joint-less Copper Plated Steel Cord Winding Process
No joint process, can withstand 10 times of machine weight, completely eliminating the risk of breakage
Closely integrated with rubber and iron core, forming a seamless whole
-
Iron Core
Forged and formed, with high density, strength and toughness
Special adhesive, high bonding standard, effectively prevents iron teeth from falling off
-
Rubber For Rollers
Thick rubber track surface provides the more comfortable driving experience
Excellent deformation resistance and aging resistance, effectively preventing wheel side cracking, durable and longer service life
Technical Parameter
| Track Size (WidthxPitch) | lnner Guide Width(A) | Outer Guide Width(B) | lnner Height (C) | Outer Height (D) | Track Thickness (H) | Lug Pattern | Section View | Guide Type | Range of Link No. | Remarks |
| 320x86TK | 38 | 84 | 41 | 30 | 60 | B/C | Fig 2 | C | 48-52 | Takeuchi-type |
| 320x86B | 47 | 96 | 43 | 33 | 71 | B/C/Z/L | Fig 1 | B | 49-60 | Bobcat-type |
| 400x86B | 48 | 97 | 44 | 33 | 75 | B/C/Z/L | Fig 1 | B | 49-60 | Bobcat-type |
| 450x86B | 48 | 97 | 44 | 33 | 76 | B/C/Z/L | Fig 1 | B | 50-65 | Bobcat-type |
| 450x100TK | 47 | 102 | 48 | 44.5 | 77 | B/C | Fig 2 | C | 48-52 | Takeuchi-type |
